Transforms helmets into the ultimate defense against multiple impacts from handgun threats by law enforcement and military personnel during forced entry and breeching operations.
Because of their unique system design, all sizes of Ops-Core FAST and Sentry Helmets, and Gentex ACH/TBH helmets can seamlessly incorporate the face shield using the Ops-Core Accessory Rail Connectors (ARCs).
The ARC interface locking system provides a solid platform for the face shield.
Once mounted, the unique, internal, face shield locking mechanism secures the face shield in any position/angle desired.
The Fore/Aft adjustment maintains an effective seal with different helmet geometries as well as increases offset to accommodate masks and other equipment when needed.
When not in use, the face shield smoothly and quickly pivots up close to the head’s center of gravity for increased comfort.
The visor’s mounting arms fold in for a smaller storage footprint.
The face shield gasket minimizes the chance that liquids will drip behind the lens.
Ballistic protective lens: 9mm 124gr FMJ @ 1,400 fps (427 m/s) and 44 Cal Magnum 240gr SWCGC @ 1,400 fps (427 m/s)
Compatible with all sizes of Ops-Core FAST and SENTRY helmets, and of U.S. Army ACH helmets, USMC LWH Type I and MICH Type II helmets, and Gentex Tactical Ballistic Helmets (TBH).
Coverage and Weight:
Coverage: 69.98 in2(451 cm2)
Maximum Weight: 2.95 lbs. (1338 g)
Testing Protocols and Design:
Gentex PRS-1016 Product Requirements Specification for Ops-Core Multi-Hit Handgun Face Shield
Modified and Abbreviated NIJ Standard 0104.02 Riot Helmets and Face Shield
Modified and Abbreviated NIJ Standard 0106.01 Ballistic Helmets using NIJ Standard 0108.01 Ballistic Materials Level IIIA threats (9mm 124gr FMJ RN at 1400 fps and .44 Cal Magnum 240gr SWCGC at 1400 fps)
Environmental affects testing: Weatherometer (accelerated aging); high temperature operating and storage; cold temperature operating and storage; and vibration.
