DOVETAIL MODEL
IN STOCK FOR IMMEDIATE DELIVERY
Description:
The GPNVG is a helmet-mounted night vision device with a wide 97-degree horizontal field of view that allows for observation and/or target identification under adverse conditions and is ruggedized for ground applications. Individual monoculars can be detached from the system and powered with included power adapter to provide a low profile handheld night vision monocular.
Features:
- Wide field of view I2 goggle
- IPD, tilt, and fore/aft adjustments with friction locks
- Environmental qualification per MIL-STD-810G
- Modular design for maintenance and supportability
- Field replaceable tube design
- Available with Dovetail mount for use with multiple helmet and mount configurations
Specifications:
MANUFACTURER L3/Harris Technologies
DIMENSIONS 5.625in(L) x 8.50in(W) x 3.75in(H)
WEIGHT 27.0 oz
FINISH FDE, Corrosion Resistant
POWER Four (4) 3V CR123A Batteries (Remote)
BATTERY LIFE Approx. 30 Hours
IMMERSION One Meter for Two Hours
WARRANTY 1 Year Warranty
GENERATION Gen3 U.S. L3Harris
TUBE TYPE Four 18mm MX-10160
MINIMUM FIGURE OF MERIT (SNR X LP/MM) 1792
FILM/PHOSPHOR Unfilmed White Phosphor (P45)
GATE Auto
GAIN Auto
MAGNIFICATION 1x
FOV 97°
DIOPTER Snap-On Windows -0.5 standard
FOCUS 18in to Infinity
INCLUDES GPNVG Goggle, Remote Battery Pack, Connection Cable, Hard Storage Box, Padded Transport Case, Batteries, Lens Cleaning Kit
