Steiner Universal Night Vision Refocus Lens

Night Vision Refocus Lenses are innovative accessories providing operators the ability to rapidly refocus their night vision view from infinity to approximately 24 inches. This allows the operator to perform momentary close-in tasks such as map-reading or weapon clearing. The operator can then instantly return the NVG to infinity by flipping the lens back to its storage position. Night Vision Refocus Flip Lenses are specifically designed for use with many of the currently fielded NVGs including: AN/AVS-6, AN/AVS-7, AN/AVS-9, AN/PVS-14, AN/PVS-15, AN/PVS-18, AN/PVS-21, AN/PVS-23, AN/PVS-31

This accessory may be attached to the objective on either side of the night vision goggle through a simple finger clamp. A lens pivots in front of the objective lens storage position. This storage position lies completely outside the optical path of the goggle.

Specifications:

• Custom focus ranges are available
• Angular Field of View: 30º
• Focus Range: ~20in to 24in
• Applications: AN/PVS-7, -14, -15, -18, -23, -31: AN/AVS-6, -9
• Dimensions: 41mm (1.6in) x 54mm (2.1in) x19mm (0.75in)
• Weight: 10.5g (0.4 ounces)
